Pipe connection tooling

overview

Pipeline connection tooling is a fast, easy to unload, high pressure and safe pipeline connection tooling. By pressing the handle, the pipeline can be quickly connected and formed a high pressure seal. It is widely used for expanding and testing pipelines.

classification

According to pipe diameter: phi 7/9.52/12/12.7/15/15.6/15.88/16/19/20/21/22/25/32/47 mm

According to the pressure: below 50MPa, 50MPa above

Specific according to user needs and customized

Scope of application

1 Hydrostatic test

2 Air tightness test

3 Pipe expansion

Technical parameter

1. Operation mode: manual

2, applicable pipe diameter: φ6-φ51mm (specific sample customized)

3, the highest pressure: 150MPa
